SMARTDOG

SmartDog TS

Wall-mountable
Large connection compartment for easy cable installation
Flip-open design for convenient access to the connection area
Practical bottom cable entries to prevent insect ingress
7" color display with capacitive touch
Power supply via 24V terminals or plug-in power adapter
Configuration via display or integrated web server

SmartDog PN

Designed for installation in a cabinet door or piece of furniture
Rear cable connection
Perfect for EV charging cabinets with a clear, easy-to-read display
7" color display with capacitive touch
Power supply via 24V terminals or plug-in power adapter
Configuration via display or integrated web server

SmartDog DR

Designed for DIN rail mounting in control cabinets
Compact design with 9 TE (modular width units)
Power supply via 24V terminals or plug-in power adapter
Configuration via integrated web server

SmartDog – Your Energy Management System for Efficient Energy and Cost Optimization

SmartDog® is an energy management system designed for both modern households and commercial or industrial applications, with a strong focus on renewable energy integration.

A wide range of modules is available to suit every use case — from certified EZA controllers for megawatt-scale PV parks to intelligent battery management with dynamic electricity pricing and weather forecasting, load management for charging stations, and surplus charging of immersion heaters, heat pumps, EV chargers, and more for both residential and commercial systems.

All devices are remotely configurable – the perfect solution for professional system monitoring.

Informationen

Inverter communication
- Supports up to 100 inverters per SmartDog
- Compatible with up to 16 different manufacturers
- Feed-in management included
Monitoring
- Inverter failure detection
- Status and fault analysis
- Failure recognition down to MPP and string level
- Power monitoring
- String monitoring for central inverters
- Sensor monitoring
- Online portal with alert notifications
- Remote maintenance
- Email alerts
- Central park controller (Parkregler) functionality
Remote Communication – IEC 101/104
Visualization
- Integrated web server
- Internet portal access
- Mobile app support
- Local network connectivity
- Worldwide SmartDog Live access
- Real-time status display
- Support for large external displays
- Capacitive touchscreen
Interfaces
- Interfaces & Connectivity:
  - 2 × LAN
  - 2 × USB hubs
  - 4 × RS485
  - 1 × RS422
  - 1 × RS232
  - 1 × Mini HDMI
  - 1 × 1-Wire bus
- I/O Ports:
  - 2 × Relay outputs
  - 4 × Digital inputs (24VDC)
  - 4 × Digital outputs (24V / 500 mA)
  - 2 × Analog inputs (0–10 V / 0/4–20 mA)
  - 2 × Analog outputs (0–10 V / 0/4–20 mA)
  - 2 × PT1000 temperature sensor inputs
- Hardware Specs:
  - Quad-core processor (4 × 1.2 GHz)
  - 8 GB EEPROM
  - 1 GB RAM
  - 8 GB microSD storage
  - Hardware Watchdog
  - Software Watchdog
- Interfaces & Access:
  - Integrated web server
  - Internet portal access
  - Mobile app
  - Local network operation
  - Worldwide SmartDog Live access
  - Capacitive touchscreen
  - Support for large external displays
- Control & Compatibility:
  - Intelligent consumer control
  - Support for up to 100 inverters
  - Up to 16 different inverter brands
  - Battery / hybrid inverters
  - EV charging stations
  - Heat pumps
  - Heating rods (e.g., Ohmpilot, MyPV, 0–10 V)
  - Smart appliance control via wireless sockets (e.g. washing machine, dryer, dishwasher)
- SmartNet Functionality:
  - Share sensors, meters, and controls across multiple SmartDog units in the same local network
- Optional Extensions:
  - M-Bus interface for heat, cooling, gas, and water meters
- Monitoring & Alarms:
  - Inverter failure detection (down to MPP and string level)
  - Performance and string monitoring
  - Sensor supervision
  - Status and fault analysis
  - Online portal with alarm notifications
  - Remote maintenance
  - Email alerts
  - Integrated park controller (central feed-in management)
Hardware Expansion
- Digital & Analog Inputs/Outputs:
  - 8 × Digital inputs, 8 × Digital outputs
  - 8 × Analog inputs (0–10 V or 0/4–20 mA)
  - 4 × Analog outputs (0–10 V or 0/4–20 mA)
  - 24 × Digital inputs, 6 × Relay outputs
  - 10 × Digital inputs
  - 4 × Relay outputs with H-0-A (Hand-Off-Auto) switches
  - 8 × Temperature / analog inputs (supports 15 different sensor types)
  - 1 × Analog output (0–10 V)
  - 4 × Analog outputs (0–10 V)
- Sensor & Device Integration:
  - Dual S0 energy meter input
  - Up to 20 OneWire temperature sensors
  - OneWire sensors for humidity, air pressure, brightness, temperature
  - OneWire air quality sensors
- External Module Support:
  - Adam 4022T – Analog I/O module
  - Adam 4068 – 8-channel relay output module
  - Adam 4050 – 16-channel digital I/O module
  - Woodward Q(U) protection device via Modbus TCP
- Smart Home Integration:
  - MyStrom Wi-Fi smart plug with temperature sensing
  - Shelly sensors – Cloud-based integration
  - Shelly sensors – Local integration
String Monitoring
- Phoenixcontact
- Solarmax
- Kaco Stringcontrol

Kompatibel mit einer Vielzahl an Wechselrichtern, Batteriespeichern und Ladestationen

SmartDog – Core Functions

All SmartDog devices (whether SmartDog 100 or 1000, TS, PN, or DR) come equipped with the same interface capabilities as standard.

Typically, the device is selected based on your specific application requirements.

However, every unit can be upgraded at any time with additional licenses to unlock further functionality — providing maximum flexibility and scalability for your energy management needs.

SmartDog 100

SmartDog 1000

SmartDog 100 is the optimal device for residential and commercial systems up to 100 kWp with many useful features.

The SmartDog 1000 is the ideal device for commercial systems > 100 kWp as well as solar parks.

The device is certified as a VDE 4110 EZA controller for medium-voltage systems (license required).

The system can be expanded as needed through the use of a master/slave configuration.

The system can be controlled via remote control technology using the IEC 101 or 104 protocol.

All available interfaces can be used to integrate inverters, storage systems, meters, heating elements, charging stations, etc.

All modules for surplus control of heating elements, wallboxes, heat pumps, etc. are available to you.

Inverter control via FRE or remote control technology is possible here.

Remote control connection via IEC 101 or 104 protocol integrated.

Über das Portal oder per APP können Sie auf den SmartDog in Echtzeit zugreifen und diesen konfigurieren und Ihren Kunden zeitsparend helfen!

Inverter control via FRE or remote control technology is possible here.

Direct marketing is also supported

The EZA controller license or TOR generator license (Austria) cannot be activated on this device – for this, the device must be upgraded to SmartDog 1000.

Via the portal or app, you can access the SmartDog in real time, configure it, and assist your customers efficiently!

Information About Your Energy Flows

Web Portal

The SmartDog Portal provides comprehensive insights into your energy flows.

Installers can clearly manage their customers’ systems and customize the portal with their own logo and colors.

A user-friendly app allows you to configure the charging modes of various devices, view clear energy flows, and generate reports — giving you optimal control over your system.

Other data logger manufacturers are also supported and can send their data to our portal.

SmartDog-Live access in real-time

Support

Our technicians have been in the business for many years and understand the issues that can arise during commissioning.

They possess expert knowledge in electrical engineering as well as in resolving hardware and software issues!

Whether it's configuration, connection, or setting problems in third-party products – we're here to support you!
